Heavy Duty Eurogroove

HD10R EURO NOTCH , HD16R EURO NOTCH , HD22 EURO NOTCH

Heavy-Duty friction stay with euro groove fitment. Improved manufacturing lead-times for  aluminum profiles. Easy to fit with adjustable friction mechanism. Friction stay stack height 16-17mm Corrosion resistance meets the requirements of BS 7412:1991. Manufactured from high-grade Austenitic Stainless Steel for maximum longevity. Even in the most corrosive environments. Composite steel/plastic slider for strength, durability and smooth operation. The Heavy Duty range has been proven to a lifetime 50,000 cycles. The Heavy Duty friction stays conforms to all leading international window performance standards in the UK (S6375 Part 2 1987), North America (AAMA 904.1), France (NF-20-302) and Singapore (SS 212 1998). On any windows over 32Kg we recommend that you fit our Heavy Duty Friction / Restriction Arms (HD102)

Get a quote

Specifications

RECOMMENDED MAXIMUM WINDOW WEIGHTS & SIZES
PRODUCT TOP/SIDE HUNG SIZE INS SIZE MM WINDOW SIZE
APPROX WIDTH MM		 WINDOW SIZE
APPROX HEIGHT MM		 WINDOW WEIGHT APPROX KG MAXIMUM
OPENING ANGLE
HD10R TOP 10 262 2000 650 50Kg @ 50 ° & 40KG @ 84° 50° & 84°
HD16R TOP 16 415 2000 800 100Kg @ 30°, 55Kg @ 50° & 50Kg @ 90° 30°, 50° or 90°
HD10R SIDE 10 262 660 1524 34.5Kg 50° & 84°
HD16R SIDE 16 415 762 1619 42Kg 30°, 50° or 90°
HD16R SIDE 16 415 700 1600 60Kg @ 30° & 50°, 42Kg @ 90° 30°, 50° or 90°
RECOMMENDED MAXIMUM WINDOW WEIGHTS & SIZES
PRODUCT APPLICATION SIZE INS SIZE MM WINDOW SIZE
APPROX HEIGHT MM		 WINDOW WEIGHT
APPROX KG		 STACK
HEIGHT MM		 MAXIMUM
OPENING ANGLE
HD22SB TOP HUNG 22 567 1500 100 @ 20° & 80 @40° 6.5 – 17.5 20° & 40°
HD26-180 TOP HUNG 27 689 2500 180 6.5 – 17.5 20°
HD22SB TOP HUNG 28 707 2200 100 6.5 – 17.5 20°
