Limit Arm (Type-1)


Stainless steel arm; zamak fixing accessories. Sash height from 600 mm to 1600 mm. Maximum capacity 70kg, it varies depending on the size and the angle of opening of the window. Euro-groove and groove profiles 20mm

Get a quote


PART NO. PE1115.1
Package 25 sets
Applicable in Standard Euro groove Type 1: 15-20 groove in the shutter & 14-18 groove in the outer frame. Also applicable in Standard Euro groove A02 – A06 – A07 – A10 – A11 – A14 – A16
Type of Window / Door Side hung, top hung, bottom hung, Open out and open in windows
